System Configuration
ZW-7000/5000
User's Manual
2
Installation and Connections
41
Connection Compatibility
• EtherCAT and EtherNet/IP connections cannot be used at the same time.
• Can be connected simultaneously via Ethernet with PC tools (Sysmac Studio, S
martMonitorZW) and another
device (PLC etc). Can be connected simultaneously via Ethernet with PC tools (Sysmac Studio, SmartMonitorZW)
and another device (PLC etc). The port number for the PC tool is 9600 (fixed) and 9602 (fixed). When connecting
different devices, set the port number to other than 9600 and 9602 (default value is 9601).
Connected to
ZW-7000@
ZW-5000@
Other connection
EtherCAT EtherNet/IP Ethernet
(no-protocol)
RS-232C
(no-protocol)
I/O Cable
EtherCAT --- Not compatible Compatible Compatible Compatible
EtherNet/IP Not compatible --- Compatible Compatible Compatible
Ethernet
(no-protocol)
Compatible Compatible --- Compatible Compatible
Ethernet
(programmable no-
protoc
ol)
Compatible Compatible Compatible --- Compatible
Product Model Application
ZW ZW-7000@/5000@ This Displacement Sensor performs measurements.
PC Tool Sysmac Studio Standard
Edition
• SYSMAC-SE200D
(no licenses included
(me
dia only))
• SYSMAC-SE201L
(1-license edition)
• SYSMAC-SE2@@L
(multilicense editions
(
3, 10,
30, or 50
licenses))
Sysmac Studio
Measurement Sensor
Edition
• SYSMAC-NE00@L
(1 or 3 licences)
This is the setup application. It is part of the Sysmac Studio Package and it
r
uns on Windows
.
The Sysmac Studio comes in two different editions.
• Sysmac Studio Standard Edition
The Sysmac Studio provides an integrated development environment for
the
NX/NJ ser
ies Controllers and other Machine Automation Controllers
and EtherCAT Slaves. It supports setup, programming, debugging,
operation, and maintenance.
The Sysmac Studio Standard Edition DVD includes Support Software for
EtherNet/
IP, DeviceNet, serial communications, and PT screen design
(CX-Designer). Refer to the Sysmac catalog (Cat. No. P072) for details.
• Sysmac Studio Measurement Sensor Edition
This license provides the functions that are required to set up ZW-7000/
5000 Series Vision Sensors from the Sysmac Studio. This model number
is for the license only. You must also purchase the DVD for the Sysmac
Studio Standard Edition Ver.1.15 or higher.
Special EtherCAT Cable Refer to 10-1
Specifications and
Dimensions
The Special EtherCAT Cable connects the Sensor to another Sensor or to
another EtherCAT device.
General-purpose Ethernet
cable
--- Prepare commercially available Ethernet cable
satisfying the following requireme
nts:
• Category 5e or more, 30 m or less
• RJ45 connector (8-pin modular jack)
• For direct connection: Select cross cable.
• For connection through an industrial switching hub: Select straight cable.
Special I/O Cable For connecting to a PLC
or programmable terminal
•ZW-XPT2
For connecting to a PC
•ZW-XRS2
Connect the sensor with a PLC, programmable terminal, or personal
computer etc..
Industrial EtherNet/IP /
Ethernet Switching Hub
• W4S1-03B
(3 ports type)
• W4S1-05B
• W4S1-05C
(5 ports type)
The Switching Hub connects multiple Sensors to one Touch Finder or one
computer running PC Tool.
To Next Page
