ZW-7000/5000
User's Manual
RUN (run) Mode Menu
Setting Option/Setting Range Pages
System
setting
[SYS
TEM
Width of input
signal filter
[FLT.WDT]
Width of input
signal filter
[FLT.WDT]
5
μ
s[5US]/10
μ
s[10US]/20
μ
s[20US]/
50
μ
s[50US]/100
μ
s[100US]*/
200
μ
s[200US]/500
μ
s[500US]/
1000
μ
s[1000US]
*1
(cont'd)
Key lock
[LOCK]
Key lock
[LOCK]
Off [OFF]*/On [ON] p.243
Zero reset
MEMORY
[ZER.MEM]
Zero reset
memory
[ZER.MEM]
Off [OFF]*/On [ON] p.233
TIMING/
RESET key
input
[KEY.IN]
TIMING/
RESET key
input
[KEY.IN]
OFF [OFF]*/ON [ON] p.227
Controller
information
[C.INFO]
Software
vers
ion
[VER]
Displays the version.
p.242
MAC Address
[MAC.ADR]
Displays the current MAC address.
Error history
[ERR.LOG]
Clears/displays the error history.
−
Error history
display
[LOG.DSP]
No.01 to No.64
(default value: No.01)
−
Error clear
[LOG.CLR]
OK [OK]/Cancel [CAN]
−
Energization
time (h)
*2
[RUN.TIM]
Energization time (h) p.178
Sensor head
information
[H.INFO]
Model
[MODEL]
Displays the model.
p.242
Serial No.
[SER.NO]
Displays the serial No..
*1. For more detail, refer to the following.
2-1 Connecting Parallel I/O in Confocal Fiber Type Displacement Sensor User's Manual for Communications Settings
(Cat. No.Z363).
*2. “- - - - - -” is displayed when the cumulative energization time flag written in the backup ROM is OFF.
Setting [DISPLAY] Option/Setting Range [DISPLAY] Pages
Task for displayed target [DISP] TASK1/TASK2/TASK3/TASK4
p.204
HIGH threshold value [H.JUDGE] Sysmac Studio: -999.99 to 999.999
Sysmac Studio:-999.999999 to 999.999999
p.205
LOW threshold value [L.JUDGE] Sysmac Studio: -999.99 to 999.999
Sysmac Studio: -999.999999 to 999.999999
p.205
Decimal point digit [DEC.NUM] 0[0DIG]/1 [1DIG]/2 [2DIG]/3 [3DIG]/4 [4DIG]/5 [5DIG]
p.204
