Setting Sensing
ZW-7000/5000
User's Manual
207
Sensor controller operations
7
Setting the Material of the Target to Measure
Setting the Material of the Target to Measure p.117
As an example, here is an explanation of the procedure for the “MIRROR” setting as the material.
Operating procedure
Steps Key operation Display Description
1 Press and hold the key for two seconds to enter the FUNC
mode.
2 Press the / keys to select “SENS” and press the
key.
3 Press the / keys to select “OBJECT” and press the
key.
4 Select the material.
NORMAL: Normal
MIRROR: Mirror
DIFF: Diffusion surface
The current setting value is displayed on the sub-display.
Press / key to enter editing mode and the sub-display blinks.
In this example, select “MIRROR” and press the
key.
5 Press the key for two seconds to enter the RUN mode.
To Next Page
