Switching operation modes

ZW-7000/5000

User's Manual

199

Sensor controller operations

7-4 Switching operation modes

3-2 Switching operation modes p.90

Use key to switch between the operation modes.

The RUN indicator identifies the current operation mode.

RUN mode: Turned on.

FUNC mode: Turned off.

To switch between the RUN

and FUNC modes, press and

hold the button for two

seconds.

Default Chapter13
