Omron ZW-7000 Series User Manual

Installation
ZW-7000/5000
User's Manual
2
Installation and Connections
59
• Handling fiber cables
Use them in compliance with the following. This may result in damage to the fiber cable.
- Fiber cable bend radiuses must be at least 20 mm.
- Do not yank hard on a fiber cable.
- Do not step on a fiber cable or place anything heavy on it.
- Do not apply any twisting stress to the fiber cable.
- Do not forcefully insert, or bend, or twist in a manner that would cause stress o
n the fiber connector when
connecting it.
- Do not let bending cause stress at the root section of a fiber connector and
connection.
• Do not touch the end surface of a fiber cable, or the cable ma
y be degraded in performance. Should the end surface
be touched or soiled, wipe the dirt away using a commercially available cleaner exclusive for fiber or dry and soft
cloth. Do not use a cloth moistened with alcohol, or the dirt may be reattached.
• Use optional ZW-XCL or commercially a
vailab
le fiber cleaner when cleaning the groove of the fiber connector. For
how to clean the fiber connector using ZW-XCL, refer to the
Cleaning the fiber connector and fiber cable using
ZW-XCL (p.60)
.
• If you frequently insert and extract the Sensor Head, recommend to use the comme
rcially available fiber cleaner
which can use repeatedly.
l ZW-7000 Series
l ZW-5000 Series
• Contact
[Request for an Estimate]
URL http://www.ntt-at.com/product/optical_cleaner/Distributors
.html
[Technical and other inquiries]
Company NTT Advanced Technology Corporation
Address Muza Kawasaki Central Tower, 1310
Omiya-cho Saiwai-ku, K
aw
asaki-shi,
Kanagawa, 212-0014, Japan
TEL +81 44 589 5894
URL http://www.ntt-at.com/product/optical_cleaner/Distr
ibutors
.html
• When you remove the fiber cable from Sensor Controller, make sure to attach the protective cap. If you do not
attach it, it is possible that some contaminants may h
ave adhered and may cause degradation of performance.
• Calibrate the Sensor Head after removing and inserting a fiber cable.
Calibrating Sensor Head p.66
• For checking the fiber is broken, confirm the followings.
Confirm by looking the Sensor head is lighting with
connecting to Sensor Controller. To put the diffraction, i.e.. a
paper to around the measurement center of Sensor head, you can confirm by looking.
When the measurement of the high reflection, you may not confirm by
looking due to adjustment of intensity
automatically.
• Cleaning the fiber connector and fiber cable using ZW-XCL, f
ollow the procedures.
Product name Model Manufacture
NEOCLEAN-M ATC-NE-M1 NTT Advanced Technology Corporation
Product name Model Manufacture
OPTIPOP R1 ATC-RE-01 NTT Advanced Technology Corporation
Important
