CHAPTER 6
Oracle FS System Cables
Types of External Cables
Customers must supply their own Ethernet cables for connecting the Pilots to the
customer management network and for connecting the Controllers to the
customer data network. Oracle has no cable color requirements for connecting
the Oracle FS System to the customer network.
Pilot External Cables
Pilot external cables provide the management connections. Ethernet CAT6a
cables connect from the NET 3 ports on the Pilot nodes to the customer
management network. The connections to the customer management network
must be to a highly available switch.
Controller External Cables
Controller external cables provide the connections for the host data path. Optical
cables connect the SAN HBA ports on the Controller to the customer data
network. Each connection requires an HBA and a specic SFP to provide the
interface option.
The following table provides the part number and description of the SAN HBAs.
Table 24: SAN HBA
Part number Description
7101673 Sun Storage 16Gb Fibre Channel PCIe Universal HBA,
Qlogic, factory congure
The following table lists the SFP options.
102
