Note: The colors of the cables that are shown in the gure are for illustration
purposes and do not reect the actual colors of the cables that are used to cable
the Oracle FS System.
Figure 83: SAS wiring diagram for Controllers to Drive Enclosures (base)
Legend
1 PCIe3 slot 3, SAS HBAs
port 2 and port 3 connect the
Controllers
3 PCIe3 slot 3, SAS HBAs port 1 connects to Drive
Enclosure string 2
2 PCIe3 slot 3, SAS HBAs
port 0 connects to Drive
Enclosure string 1
The following gure illustrates the SAS cabling of the Controllers in a
performance system congured with six Drive Enclosure strings.
Note: The colors of the cables that are shown in the gure are for illustration
purposes and do not reect the actual colors of the cables that are used to cable
the Oracle FS System.
Wiring Diagrams
128
To Next Page
