Figure 69: Example of mini-SAS to mini-SAS cable connectors
Internal Power Cords
The following table lists the types of power cords and lengths of power cords
that connect the hardware components to the power distribution units (PDUs).
Note: The references to PDU 1 and PDU 2 in the following table indicate that the
connections are to be made to separate PDUs connected to separate external
power sources for system redundancy. The actual number of PDUs in a system
can vary.
Oracle FS System Cables
108
