Controller Power Supply LED Indicators
The LED indicators on the power supplies are at the left of the fan of each power
supply and provide power activity status.
Table 41: Controller power supply LED status and description
Icon Location Name Color Status and meaning
Top OK Green
•
On – Power supply
is functional
without fault.
•
O – Power supply
is o or
initializing.
•
Flashing – No
function.
Middle
Aention
Service
Required
Amber
•
On – Normal fault
detected.
•
O – No faults
detected.
•
Flashing – No
function.
Boom
AC or DC Green
•
On – Input power
present and good.
•
O – Input power
not present.
•
Flashing – No
function.
Controller Fan LED Indicators
A single bi-color LED represents the status of each fan module. The LEDs are on
the motherboard near each fan module, and are visible from the back panel of
the Controller when you look through the grill below the risers.
Table 42: Controller fan LED status and description
Color Status and meaning
Green The fan module is functional without fault.
Amber The fan module has experienced a fault.
Note: There are two LEDs near the status LED for the third fan module. Do not
confuse the FPGA Good and FPGA Diagnostic LEDs with the status LED for the
third fan module.
Oracle FS System LED Status
201
