Figure 24: Inner CMA connector mounted
Legend
1 Slide rail
2 Inner CMA connector
3 Clip
3 Insert the outer CMA connector into the end of the right sliding rail.
Figure 25: Outer CMA connector attached
Install Component Rails
59
