Round
•
Threaded (must be M6 or 10-32 racks)
The following gure shows examples of supported rack holes.
Figure 27: Examples of supported rack holes
Legend
1 Square holes 3 Threaded holes
2 Round holes
The following gures show the rails for both Drive Enclosure types.
Figure 28: Rails for the DE2-24P Drive Enclosure
Install Component Rails
61
To Next Page
