Oracle FS1-2 Installation Guide

Table 7: Pilot power characteristics (continued)
Power
characteristic
Value
Maximum
power
consumption for
both nodes
314 VA
Current draw
for both nodes
1.42A, 208V
Maximum heat
dissipation
1102 BTU/hr
AC receptacle
type
IEC 60320 C14 inlet
Table 8: Controller power characteristics
Power
characteristic
Value
Frequency
(nominal)
50–60 Hz (47–63 Hz range)
Voltage
(nominal)
100 to 127/200 to 240 Volts AC
Input current
(maximum) for
both nodes
13.6 A at 100–120 Volts AC (approximately)
8 A at 200–240 Volts AC (approximately)
Maximum
power
consumption for
both nodes
874 VA (power at maximum FS1 Controller conguration)
Maximum heat
dissipation
2830 BTU/hr
AC receptacle
type
IEC 60320 C14 inlet
Oracle FS Systems: Installation Overview
23
