Pilot Drive LED Indicators
There are three LEDs on each Pilot drive. There is only one drive in each Pilot.
Table 49: Pilot drive LED status and description
LED Icon LED color Status
OK to Remove Blue The storage drive can be
removed safely during a hot-
swap operation.
Service
Required
Amber
•
OFF – Normal
operation.
•
STEADY ON – The
system has detected a
fault with the storage
drive.
OK/Activity
Green
•
OFF – Power is o or the
system does not
recognize the installed
drive.
•
STEADY ON – The
drive is engaged and is
receiving power.
•
STEADY BLINK – There
is disk activity. Indicator
blinks on and o to
indicate activity
Pilot Fan LED Indicators
Each Pilot fan module has one bicolored LED. These LEDs are on the Pilot side
wall next to the fan modules and are visible when the top cover fan door is open.
Table 50: Pilot fan LED status and description
LED Icon LED color Status
Fan Status
LED
NONE Bicolored:
Amber/
Green
•
Amber – There is a fan fault.
•
Green – Fan is properly installed
and operating correctly. No fan
errors detected.
Oracle FS System LED Status
214
