Oracle FS1-2 Installation Guide

Table 31: Power cords and PDU connections
Cable Color Cable path Quantity Cable
length
Power (C13 to C14
angled connector)
Black Connects power
cooling module 1
of a Drive
Enclosure to PDU
1
Connects power
cooling module 2
of a Drive
Enclosure to PDU
2
Varies based on
the conguration
of the system
3.28 feet
(1 m)
Power (C13 to C14
straight
connectors)
Black Connects power
supply 1 of a Pilot
to PDU 1
Connects power
supply 2 of a Pilot
to PDU 2
Connects power
supply 1 of a
Controller to PDU
1
Connects power
supply 2 of a
Controller to PDU
2
Connects power
supply 1 of a
MaxRep
Replication
Engine to PDU 1
Connects power
supply 2 of a
MaxRep
Replication
Engine to PDU 2
Varies based on
the conguration
of the system
9.84 feet
(3 m)
Oracle FS System Cables
109
