Table 22: Drive Enclosure rail kits
Type of Drive
Enclosure
Contents
DE2-24P Drive
Enclosure
2 Phillips Number 2 pan head screws with patch lock
2 Phillips hex ange head screws (11mm)
1 Left-hand rail assembly
1 Right-hand rail assembly
4 Phillips Number 2 ACR hex ange screws
1 10mm wrench
8 Threaded rack adaptor pegs
1 Threaded rack adaptor kit label
4 Phillips hex ange screws (13mm)
DE2-24C Drive
Enclosure
2 Phillips Number 2 pan head screws with patch lock (M5 x 16)
1 Left-hand rail assembly
2 Phillips hex ange head screws (11mm)
1 Right-hand rail assembly
2 Cage nuts
4 Orange service screw labels
2 Clip nuts
8 Special screws for round hole rack
1 Rail kit user label
2 Phillips Number 2 pan head screws with patch lock (M5 x 6)
4 Phillips hex ange head screws (13mm)
4 Phillips Number 2 ACR hex ange head screws
To locate part numbers for the rail kits, open Oracle System Handbook (hps://
support.oracle.com/handbook_private/index.html) and go to the Oracle FS1
Flash Storage System components list. Part numbers are listed in the components
list.
Install Component Rails
63
