Oracle FS1-2 Installation Guide

Table 43: Controller ESM LED status and description
Icon Location Name Color Status and meaning
Top Ready to
Remove
Blue
•
On – ESM can be
removed as a hot-
swap operation.
•
O – Do not
remove the ESM.
•
Flashing – ESM is
initializing.
Middle
Aention
Service
Required
Amber
•
On – Normal fault
is detected.
•
O – No faults are
detected.
•
Flashing – No
function.
Boom
OK/Activity Green
•
On – ESM is
functional without
fault.
•
O – ESM is o or
initializing.
•
Flashing – ESM
read and write
activity.
Drive Enclosure LED Indicators
The LED indicators on the operator panel of the Drive Enclosures provide system
status. The LED display identies the Drive Enclosure by its numeric identier.
The following gures show the operator panel LEDs for both types of Drive
Enclosure.
Oracle FS System LED Status
203
