Legend
1 Power and activity indicator 2 Drive fault indicator
The following table provides status information on the drive LEDs.
Table 47: Drive Enclosure LED status and description (drives)
Status Power/Activity Indicator
(green)
Drive Fault indicator
(amber)
Drive is installed
and operational.
On and blinking with startup
or activity
O
The drive is located. On Flash one second on and one
second o
A drive fault is
present.
On On
In addition to the continuous
amber light on the Drive Fault
LED, the Locate LED on the
operator panel is also a
continuous amber light.
A failure occurred
in the power control
circuit.
O On
In addition to the continuous
amber light on the Drive Fault
LED, the Module Fault LED on
the operator panel is also a
continuous amber light.
A failure occurred
in the disk array.
On Flash three seconds on and one
second o.
In addition to the ashing
amber light on the Drive Fault
LED, the Locate LED on the
operator panel is also a
continuous amber light.
Pilot LED Indicators
The Pilot LEDs are on the front panel of the Pilot. Use these diagnostic LEDs to
determine if a component has failed in the Pilot.
The following gure shows the LEDs at the front of the Pilot:
Oracle FS System LED Status
209
