to the Oracle FS System to indicate that it is operating in baery mode or in
normal mode and that the Oracle FS System should be congured to receive the
traps. For more information about managing APC products that can be
monitored and congured with SNMP, see the Schneider Electric MIB Reference
Guide (hp://www.apcmedia.com/salestools/JGAY-83UPH9/
JGAY-83UPH9_R0_EN.pdf). In short, a UPS system must be based on the
maximum waage requirements of the sum total of all the Oracle FS System
components.
Related Links
Planning for a System Installation
Unpacking Systems
Check and Receive Components
System Power Requirements
PDU Hardware Specications
Component Chassis Hardware Specications
Component Chassis Hardware Specifications
The following tables provide information on the hardware specications and the
power characteristics of the Pilot, Controller, and Drive Enclosures.
Dimensions and Weight
Table 3: Pilot dimensions and weight
Attribute Value
Height 1.68 in (4.26 cm)
Width Server chassis (not including ears): 17.19 in (43.65 cm)
Server chassis (with bezel): 18.90 in (48.24 cm)
Depth (not
including power
supply handles)
29.00 in (73.66 cm)
Weight 40 lb (18.1437 kg): Weight of one Pilot.
Table 4: Controller dimensions and weight
Attribute Value
Height 3.45 in (8.76 cm)
Width 17.52 in (44.55 cm)
Oracle FS Systems: Installation Overview
21
