Oracle FS1-2 Installation Guide

Table 17: Component placement with one Replication Engine (continued)
Component type RU space for installation RU space if a DE2-24C
DE follows RU 16
Controller-2 RU 25, RU 26 RU 23, RU 24
Remaining Drive Enclosures RU 27 to RU 42
RU 25 to RU 28 (next
DE2-24C DE)
RU 29 to RU 42
If the Oracle FS System includes two Replication Engines, then follow the
placement shown in the following table:
Table 18: Component placement with two Replication Engines
Component type RU space for installation RU space if a DE2-24C
DE follows RU 14
Drive Enclosures RU 1 to RU 16 RU1 to RU14
Replication Engine-2 RU 17, RU18 RU 15, RU 16
Replication Engine-1 RU 19, RU 20 RU 17, RU18
Pilot-0 RU 21 RU 19
Pilot-1 RU 22 RU 20
Controller-1 RU 23, RU 24 RU 21, RU 22
Controller-2 RU 25, RU 26 RU 23, RU 24
Remaining Drive Enclosures RU 27 to RU 42
RU 25 to RU 28 (next
DE2-24C DE)
RU 29 to RU 42
If the Oracle FS System includes three Replication Engines, then follow the
placement shown in the following table:
Table 19: Component placement with three Replication Engines
Component type RU space for installation RU space if a DE2-24C
DE follows RU 12
Drive Enclosures RU 1 to RU 14 RU 1 to RU 12
Replication Engine-3 RU 15, RU 16 RU 13, RU14
Replication Engine-2 RU 17, RU 18 RU 15, RU 16
Replication Engine-1 RU 19, RU 20 RU 17, RU 18
Pilot-0 RU 21 RU 19
Pilot-1 RU 22 RU 20
Controller-1 RU 23, RU 24 RU 21, RU 22
Prepare for System Installation
38
