Controller ESM LED Indicators
Three LEDs represent the status of each energy storage module (ESM). The LEDs
are above the release buon of each drive.
Figure 104: Controller drive LEDs
Legend
1 Ready to Remove LED 3 OK/Activity LED
2 Aention Service Required LED
This following table describes the functionality of the ESM LEDs:
Oracle FS System LED Status
202
