Oracle FS1-2 Installation Guide

System Components
An Oracle Flash Storage System consists of Pilots, Controllers, and Drive
Enclosures. Replication Engines can also be added to the system for replication
purposes.
The following table summarizes the components that comprise the Oracle FS
System along with their model name, quantity, and description.
Table 2: Oracle FS System component descriptions
Component name Model Quantity and description
Pilot 1U An Oracle FS System supports two
Pilot management controllers.
The Pilot nodes are designated as
Pilot-1 and Pilot-2. One Pilot node
actively performs management
functions while the other Pilot node is
in standby mode. The Pilot in an
Oracle FS System operates separately
from the user data and the command
paths and thus provides out-of-band
management.
Controllers 2U An Oracle FS1-2 supports two storage
Controllers. The Controllers are
designated as Controller-1 and
Controller-2. Both Controllers actively
process I/O on the data path.
Note: Controllers are identied in the
CLI as CONTROLLER-01,
CONTROLLER-02 and in the
Oracle FS System Manager as
CONTROLLER 01, CONTROLLER 02.
Drive Enclosures
•
DE2-24P (2U), 24
SFF, 2.5 inches
(6.35
centimeters)
SAS-2 drives or
7, 13, 19 SSDs for
each Drive
Enclosure
•
DE2-24C (4U), 24
LFF, 3.5 inches
(8.89
centimeters)
SAS-2 drives
An Oracle FS1-2 supports between 1-
30 Drive Enclosures. Both DE2-24P and
DE2-24C can coexist in the same
system.
