Figure 30: 10mm wrench and adaptor pins
Legend
1 10mm wrench 2 Adaptor pins
3 Position the front of the rails inside of the rack, with the rail ange inside
of the rack ange.
The rail label faces the inside of the rack. The pins should be fully located
within the rack holes.
Install Component Rails
65
