Table 25: HBA options with SFPs
SFP option SFP manufacturing part
number
Description
16Gbs FC Optic SR 7023325 Used for bre channel
networks (includes one pair
of SFPs)
10Gbs iSCSI Optic SR 7023315
Used for iSCSI (includes one
pair of SFPs)
The following table summarizes the length limits for the optical cables that
connect to the Controller SAN ports:
Table 26: Cable length limits for FC configurations
Speed OM1 OM2 OM3 OM4
8 Gb/s 68.89 feet (21
meters)
164.042 feet
(50 meters)
492.126 feet (150
meters)
623.36 feet (190
meters)
10 Gb/s
(iSCSI)
108.268 feet
(33 meters)
272.31 feet
(83 meters)
984.252 feet (300
meters)
1804.46 feet (550
meters)
16 Gb/s 49.21 feet (15
meters)
114 .89 feet
(35 meters)
328.084 feet (100
meters)
410.105 feet (125
meters)
Related Links
Handling and Care of Fiber Optic Cables
Types of Internal Cables
Types of Internal Cables
The types of internal cables for the Oracle FS System are summarized in the
sections below.
Note: If you require additional internal cables, you can order them from Oracle.
To nd the cable part numbers for ordering purposes, open Oracle System
Handbook (hps://support.oracle.com/handbook_partner/index.html) and go to
the Oracle FS1 Flash Storage System components list. Part numbers are listed in
the components list.
Private Management Network Cables
The following table lists the types of internal cables and the cable lengths that are
used for the Private Management Network.
Oracle FS System Cables
103
