Oracle FS1-2 Installation Guide

CHAPTER 2
Prepare for System Installation
Prepare for Installation
Component Placement
Oracle recommends the following rack unit (RU) locations for installing the
components in the rack:
Table 16: Default component placement in racks
Component type RU space for installation RU space if a DE2-24C
DE follows RU 18
Drive Enclosures RU 1 to RU 20 RU 1 to RU 18
Pilot-1 RU 21 RU 19
Pilot-2 RU 22 RU 20
Controller-1 RU 23, RU 24 RU 21, RU 22
Controller-2 RU 25, RU 26 RU 23, RU 24
Remaining Drive Enclosures RU 27 to RU 42
RU 25 to RU 28 (next
DE2-24C DE)
RU 29 to RU 42
If the Oracle FS System includes one Replication Engine, then follow the
placement shown in the following table:
Table 17: Component placement with one Replication Engine
Component type RU space for installation RU space if a DE2-24C
DE follows RU 16
Drive Enclosures RU 1 to RU 18 RU 1 to RU 16
Replication Engine-1 RU 19, RU 20 RU 17, RU 18
Pilot-0 RU 21 RU19
Pilot-1 RU 22 RU20
Controller-1 RU 23, RU 24 RU 21, RU22
37
