Legend
1 SSN label
2 Rack
3 Aach the World Wide Node Number (WWnN) label on the chassis of the
boom Controller at the front to the right of the Controller product serial
number label.
Figure 10: WWnN location: (Controller front next to SSN label)
Legend
1 Pre-existing Controller SSN label on the chassis
2 WWnN label
3 Controller front
Prepare the Rack
Not-racked systems require preparation of the rack prior to component
installation and cabling into the rack. Refer to the vendor’s rack documentation
for detailed information on unpacking the rack, positioning the rack, and
stabilizing the rack.
To create a bay of racks, rst remove the adjacent (inner) side panels from each
rack and move the racks into position. You must route the cables directly from
one rack to the other through the open sides of the racks because the cables are
not long enough to route through a raised oor.
Prepare for System Installation
43
