Oracle FS1-2

Figure 16: Slide rail assembly unlocked
Legend
1 Slide rail assembly
2 Slide rail lock buon
2 Slide the mounting bracket release buon, and then slide the mounting
bracket out of the slide rail.
Figure 17: Mounting bracket release button
Install Component Rails
52
