Oracle FS1-2

Table 33: Example of Drive Enclosure string assignments
Drive Enclosure and Drive
type
String number Drive Enclosure number within a
string
DE2-24P
400GB SSDs (peformance)
String 1 DE 1
DE2-24P
900GB HDDs (performance)
String 1 DE 2
DE2-24C
4TB HDDs (capacity)
String 1 DE 3
DE2-24P
400GB SSDs (performance)
String 2 DE 1
DE2-24P
900GB HDDs (performance)
String 2 DE 2
DE2-24C
4TB HDDs (capacity)
String 2 DE 3
DE2-24P
900GB HDDs (performance)
String 3 DE 1
DE2-24C
4TB HDDs (capacity)
String 3 DE 2
DE2-24C
4TB HDDs (capacity)
String 3 DE 3
DE2-24P
900GB HDDs (performance)
String 4 DE 1
DE2-24C
4TB HDDs (capacity)
String 4 DE 2
DE2-24C
4TB HDDs (capacity)
String 4 DE 3
Cabling Plan
123
