Table 12: High voltage single phase PDU for Oracle Flash Storage Systems
(continued)
High Voltage 1Ph (2W + ground)
Voltage input 2x [2Ph. (2W+ground)] 230Vac, 50 Hz,
maximum. 25A per phase
Can be connected to Ph-N input sources in
the range of 220V – 240V AC (nominal)
Number of input cords and plug type
2x IEC 309, 32A (Hubbell 332P6S or
equivalent)
Number of data center receptacles and
type
2x IEC 309, 32A (Hubbell 332R6S or
equivalent)
Maximum input current for each cord 25A
Outlet receptacles (number/type) 42/C13 (seven for each outlet group)
6/C19 (one for each outlet group)
Outlet groups for each PDU 6
PDU power cord length 2 meters (6.6 feet)
PDU power cords are 4 meters (13 feet)
long, but sections are connected for internal
routing in the rack.
Table 13: High voltage three-phase PDU for Oracle Flash Storage Systems
High Voltage 3Ph (5W + ground)
kVA size 15 kVA
Marketing part number 7104980
Phase 3
Voltage input [3Ph. (4W+ground)] 230/400Vac, 50/60 Hz,
maximum. 25A per phase
Can be connected to Ph-N input sources in
the range of 220V – 240V AC (nominal)
Number of input cords and plug type
1x IEC 309, 32A (Hubbell 532P6S or
equivalent)
Number of data center receptacles and
type
1x IEC 309, 32A (Hubbell 532R6S or
equivalent)
Oracle FS Systems: Installation Overview
27
