mounted in a manner such that the power cords provided by Oracle might be
used and the PDUs do not obstruct the ability to replace eld replaceable units
(FRUs) and customer serviceable units (CRUs).
While planning rack-space, ensure that adequate space is also allocated for the
PDUs, if using non-Oracle PDUs.
The following tables provide information on the various PDUs for the Oracle FS
Systems, with the assumption that there are two PDUs in each rack.
Note: The term “Ph” stands for “phase” in the above tables.
Table 10: Low voltage dual phase PDU for Oracle Flash Storage Systems
Low Voltage 2Ph (2W + ground)
kVA size 10 kVA
Marketing part number 7104982
Phase 1 Phase
No grounded neutral conductors are
provided in the two input cords.
Voltage input
2x [2Ph (2W+ground)], 208Vac, 50/60 Hz,
maximum. 24A per phase
Can be connected to input sources in the
range of 200V – 240V AC (nominal)
Number of input cords and plug type
2x NEMA L6-30P
Number of data center receptacles and
type
2x NEMA L6-30R
Maximum input current for each cord 24A
Outlet receptacles (number/type) 42/C13 (seven for each outlet group)
6/C19 (one for each outlet group)
Outlet groups for each PDU 6
PDU power cord length 2 meters (6.6 feet)
PDU power cords are 4 m (13 ft) long, but
only 2 m (6.6 ft) are usable outside of the
cabinet.
Oracle FS Systems: Installation Overview
25
