Figure 48: CMA slide rail connector inserted into the back of the left slide
rail
Legend
1 CMA slide rail connector
2 Left slide rail
Note: The CMA in the graphic is for representation only. The CMA
shipped with your Pilot might be slightly dierent.
7 Install and route cables to the Pilot, as required.
Install Component Rails
80
