Figure 33: Front of the rack and rail-location pegs
Legend
1 Rail-location pegs 2 Front rack post
4 Insert and tighten one Phillips 13mm head hex ange screw through the
front rack hole and into the top hole of the rail.
Install Component Rails
68
