Figure 105: Operator panel LEDs (DE2-24P Drive Enclosure)
Legend
1 System power indicator 3 Locate indicator and logical fault
indicator
2 Module fault indicator 4 Chassis ID
Figure 106: Operator panel LEDs (DE2-24C Drive Enclosure)
Legend
1 System power indicator 3 Locate indicator and logical fault
indicator
2 Module fault indicator 4 Chassis ID
The following table provides status information on the operator panel LEDs.
Oracle FS System LED Status
