Legend
1 NET MGT port connects to
the cluster interconnect port
on the partner Controller
(Ethernet).
4 NET 2 port connects to the NET 2 port on the
partner Controller(Ethernet).
2 Cluster interconnect
network port connects to the
NET MGT port on the partner
Controller (Ethernet). The
cluster interconnect network
port is labeled as <- - ->.
5 SAS HBA ports connect between the
Controllers and connect the Controllers to the
Drive Enclosures (SAS).
3 NET 3 port connects to the
NET 1 port on the Pilot node
(Ethernet).
Related Links
Connections to the Customer Data Network
Connect the Cables to Controller 1
Connect the Cables to Controller 2
Connect to the Customer Data Network
Drive Enclosure Cabling
Each I/O module on a Drive Enclosure has three SAS ports. The SAS ports
provide the interconnection between the Drive Enclosures and the Controllers.
The SAS ports also provide the interconnections between Drive Enclosures.
DE2-24P Drive Enclosures
The following gure shows the SAS ports of a DE2-24P Drive Enclosure. Note
the position of the SAS ports and the reverse orientation of the two I/O modules.
Remember the orientation of the I/O modules and the location of the SAS ports
as you cable the system.
Oracle FS Systems: Cabling Overview
99
