Oracle FS1-2 Installation Guide

Table 35: Two SAS HBAs per Controller (continued)
DE Add Order String
number
SAS HBA PCI
slot
Port on SAS
HBA
DE number within
string
10 2 Slot 6 0 3
11 3 Slot 3 1 3
12 4 Slot 6 1 3
13 1 Slot 3 0 4
14 2 Slot 6 0 4
15 3 Slot 3 1 4
16 4 Slot 6 1 4
17 1 Slot 3 0 5
18 2 Slot 6 0 5
19 3 Slot 3 1 5
20 4 Slot 6 1 5
The following table summarizes the string distribution for systems with three
SAS HBAs per Controller. A system with three SAS HBAs per Controller can
have one to 30 Drive Enclosures distributed across six strings.
Table 36: Three SAS HBAs per Controller
DE Add Order String
number
SAS HBA PCI
slot
Port on SAS
HBA
DE number within
string
1 1 Slot 3 0 1
2 2 Slot 6 0 1
3 3 Slot 2 0 1
4 4 Slot 3 1 1
5 5 Slot 6 1 1
6 6 Slot 2 1 1
7 1 Slot 3 0 2
8 2 Slot 6 0 2
Wiring Diagrams
132
