Oracle FS1-2 Installation Guide

Table 36: Three SAS HBAs per Controller (continued)
DE Add Order String
number
SAS HBA PCI
slot
Port on SAS
HBA
DE number within
string
9 3 Slot 2 0 2
10 4 Slot 3 1 2
11 5 Slot 6 1 2
12 6 Slot 2 1 2
13 1 Slot 3 0 3
14 2 Slot 6 0 3
15 3 Slot 2 0 3
16 4 Slot 3 1 3
17 5 Slot 6 1 3
18 6 Slot 2 1 3
19 1 Slot 3 0 4
20 2 Slot 6 0 4
21 3 Slot 2 0 4
22 4 Slot 3 1 4
23 5 Slot 6 1 4
24 6 Slot 2 1 4
25 1 Slot 3 0 5
26 2 Slot 6 0 5
27 3 Slot 2 0 5
28 4 Slot 3 1 5
29 5 Slot 6 1 5
30 6 Slot 2 1 5
Wiring Diagrams
133
