Legend
1 Left-side rail for square-hole and round-
hole racks
2 Adaptor pins for threaded-hole
racks
Figure 29: Rails for the DE2-24C Drive Enclosure
Legend
1 Left-side rail for square-hole racks 3 Round-hole racks
2 Threaded-hole racks
Drive Enclosure Rail Kits
The following table summarizes the contents of the Drive Enclosure rail kits.
Install Component Rails
62
