Oracle FS1-2 Installation Guide

Table 34: One SAS HBA per Controller
DE Add Order String
number
SAS HBA PCI
slot
Port on SAS
HBA
DE number within
string
1 1 Slot 3 0 1
2 2 Slot 3 1 1
3 1 Slot 3 0 2
4 2 Slot 3 1 2
5 1 Slot 3 0 3
6 2 Slot 3 1 3
7 1 Slot 3 0 4
8 2 Slot 3 1 4
9 1 Slot 3 0 5
10 2 Slot 3 1 5
The following table summarizes the string distribution for systems with two SAS
HBAs per Controller. A system with two SAS HBAs per Controller can have one
to 20 Drive Enclosures distributed across four strings.
Table 35: Two SAS HBAs per Controller
DE Add Order String
number
SAS HBA PCI
slot
Port on SAS
HBA
DE number within
string
1 1 Slot 3 0 1
2 2 Slot 6 0 1
3 3 Slot 3 1 1
4 4 Slot 6 1 1
5 1 Slot 3 0 2
6 2 Slot 6 0 2
7 3 Slot 3 1 2
8 4 Slot 6 1 2
9 1 Slot 3 0 3
Wiring Diagrams
131

Oracle FS1-2 Specifications

General

Model	FS1-2
Architecture	Scale-out
Form Factor	2U
Drive Type	SSD and HDD
Interface	SAS
Networking	10 GbE, 40 GbE
Storage Protocol	NFS, SMB
Data Protection	Replication
RAID Support	RAID 6, RAID 10
Data Reduction	Deduplication, Compression
High Availability	Yes
Management	Oracle FS System Manager
Operating System Compatibility	Linux, Windows
Latency	< 1 ms
