Pilot Port LED Indicators
The Pilot has LED indicators for Network Management ports and the Ethernet
ports.
Network Management Port Status LEDs
The Pilot has one 10/100BASE-T Ethernet management domain interface, labeled
NET MGT. There are two LEDs on this port. These indicators are visible from the
back of the Pilot.
Table 51: Network management port LED status and description
LED Location LED color Status
Link speed Top left Amber or
Green
•
Amber on - 10BASE-T link
•
Green on - 100BASE-T link
•
O - No link or link down
•
Flashing - No function
Activity
Top right Green
•
On - No function
•
O - No activity
•
Flashing - Packet activity
Ethernet Port Status LEDs
The Pilot has four Ethernet ports (NET 3, NET 2, NET 1, NET 0). There are two
LEDs on each port. These LEDs are visible from the back of the Pilot.
Table 52: Ethernet port LED status and description
LED Location LED color Status
Link speed Top left Green
•
On - No function.
•
O - No activity
•
Flashing - Packet activity
Activity
Top right Amber or
Green
•
Amber on - 100BASE-T link
•
Green on - 1000/10GBBASE-T
link
•
O - No link or link down
•
Flashing - No function
Oracle FS System LED Status
215
