Table 40: Controller LED status and description (back panel) (continued)
No. LED LED color Status
3
Network
management LED
•
(Left) Link
and
Activity
LED:
Green
•
(Right)
Speed
LED:
Green,
amber, or
OFF
Indicates these conditions:
•
Link and Activity LED:
•
On or blinking – A link
is established.
•
O – No link is
established.
•
Speed LED:
•
On or blinking – The
link is operating as a
100-Mbps connection.
•
O – The link is
operating as a 10-Mbps
connection.
4
Net0 to Net3
status LEDs
•
(Left) Link
and
Activity
LED:
Green
•
(Right)
Speed
LED:
Amber
Indicates the state of the service
processor:
•
Link and Activity LED:
•
On or blinking – A link
is established.
•
O – No link is
established.
•
Speed LED:
•
Amber – The link is
operating as a Gigabit
connection (1000-
Mbps).
•
Green – The link is
operating as a 100-
Mbps connection.
•
O – The link is
operating as a 10-Mbps
connection or there is
no link.
