Questa sezione descrive le operazioni da effettuare per lo smontaggio del motore dal veicolo.
Exhaust assy. Removal
- Remove the RH footrest.
- Remove the Lambda probe from its support and
disconnect it.
- Cut the fastening clamp on the lambda probe ca-
ble.
- Undo the two exhaust manifold fixings on the
head. To unscrew the nuts that fix the silencer
flange to the head properly, use a jointed wrench
that allows, according to the travel direction, to get
also at the right nut. That is difficult to do with a
traditional straight wrench.
- Unscrew the three screws fastening the heat
shield to the silencer;
- Unscrew the three screws «A» fastening the si-
lencer to the silencer mounting bracket.
- Remove the full silencer unit.
Engine from vehicle Beverly 300 i.e.
ENG VE - 102
