PIAGGIO Beverly 300 i.e. - Inspecting the Injector Circuit

Separate the lower part of the pump mounting as
shown in the picture.
Remove the filter from the pump mounting
Inspecting the injector circuit
INJECTION LOADS
Specification
Desc./Quantity
1 Battery 12V - 12 Ah
2 Fuse No. 3 10 A
3 Fuse No. 1 30 A
Beverly 300 i.e. Injection
INJEC - 185
