PIAGGIO Beverly 300 i.e. - Rear and Front Brake Calliper Service

Removal
- Remove the rear wheel.
- Remove the two rear brake calliper devices fas-
tening them to the support as shown in the picture.
N.B.
SHOULD THE BRAKE CALLIPER BE REPLACED, BEFORE
REMOVING THE FITTINGS FIXING THE CALLIPER TO THE
SUPPORTING BRACKET, FIRST LOOSEN THE OIL HOSE
FITTING AFTER HAVING EMPTIED THE SYSTEM OF THE
CIRCUIT BEING INSPECTED.
Refitting
- Follow the removal procedures but in reverse order and tighten to the prescribed torques with the
recommended product.
Recommended products
Loctite 243 Medium-strength threadlock
Medium Loctite 243 threadlock
Locking torques (N*m)
Screw tightening calliper to support 20 ÷ 25
If the calliper is replaced:
CAUTION
ONCE REFITTING IS FINISHED, BLEED THE SYSTEM.
CAUTION
ALWAYS USE NEW COPPER WASHERS.
Locking torques (N*m)
Rear brake calliper-pipe fitting 20 ÷ 25
See also
Rear - combined
Front brake calliper
Braking system Beverly 300 i.e.
BRAK SYS - 234
