PIAGGIO Beverly 300 i.e. - Fuel Tank Removal

1. Safety valve
2. Breather pipe
3.Elastic clip
4. Fuel tank
5. Side fixing screws
6. Front fixing screws
7.Hose clamp
FUEL TANK REMOVAL:
Position the vehicle on the central stand and on a flat surface.
N.B.
THIS OPERATION SHOULD PREFERABLY BE PERFORMED WITH THE TANK EMPTY.
First remove:
- the lower side fairings;
- the footrests;
- the lower central cover;
- the leg shield back plate.
Disconnect the connector of the fuel pump and the
fuel piping acting on the quick-release fitting.
WARNING
PAY ATTENTION TO THE SPILLING OF FUEL DUE TO PIPE
PRESSURE.
Disconnect the connector of the level indicator.
Remove the side screws fixing the tank to the
frame.
Chassis Beverly 300 i.e.
CHAS - 268
