Removal
- Remove the transmission cover and the com-
plete drive pulley beforehand
- Install the base of the appropriate tool on the oil
seal using the screws provided.
Specific tooling
020622Y Transmission-side oil seal punch
- Screw the threaded bar onto the base of the tool
and extract the oil seal.
Specific tooling
020622Y Transmission-side oil seal punch
Refitting
- Always use a new oil seal upon refitting
- Prepare the new oil guard by lubricating the seal-
ing lip.
- Preassemble the oil seal with the appropriate tool
by positioning the screws.
- Insert the sheath over the crankshaft.
- Insert the tool with the oil seal on the crankshaft
until it comes into contact with the crankcase.
- Insert the adaptor bushing of the tool in the hole
on the crankcase.
Engine Beverly 300 i.e.
ENG - 160
