Removing the stator
- Remove the two pickup screws and the screw
holding the wiring support and the three stator
clamping screws shown in the figure.
- Remove the stator and its wiring.
Refitting the stator
- Refit the stator and flywheel carrying out the re-
moval procedure in reverse, tightening the retain-
ers to the specified torque.
Locking torques (N*m)
Stator fixing screws 8 to 10 Pickup fixing
screws 3 to 4
Refitting the flywheel cover
- Fit the gasket and be careful with the two align-
ment dowels.
Engine Beverly 300 i.e.
ENG - 132
