PIAGGIO Beverly 300 i.e. - Swinging Arm Refitting

Refitting
In order to fit the swinging arm properly, follow
these steps:
- Position the silent block support bracket with part
«3 » pre-fitted and screw in but do not tighten part
«1».
- Position the swinging arm, inserting part « 2».
- Tighten part «3» to the prescribed torque.
- Screw and tighten part «4» to the prescribed tor-
que.
Beverly 300 i.e. Suspensions
SUSP - 225
