PIAGGIO Beverly 300 i.e. - Thermostat Removal and Testing

- Tighten the bleed valve respecting the maximum
torque.
- Bring the coolant up to the correct level inside the
expansion tank
Locking torques (N*m)
Bleed screw 3
Thermostat
Removal
- Remove the helmet compartment inspection cov-
er.
- Place a + 2.0 l container under the vehicle to col-
lect the coolant.
- Undo the two screws indicated, lift the cover and
remove the thermostat.
Beverly 300 i.e. Cooling system
COOL SYS - 249
