Cooling system
RADIATOR
Code
Action Duration
1 007001 Expansion tank - Replacement
2 007024 Expansion tank cap - Replacement
3 007013 Radiator expansion tank connection
pipe - change
4 007016 Fan with support - Replacement
5 001052 Coolant and air bleed - Replacement
6 007003 Coolant delivery and return pipe -
change
Time Beverly 300 i.e.
TIME - 334
