PIAGGIO Beverly 300 i.e. - Legshield

- Undo the indicated screw on both sides of the
vehicle;
- Release the fastener clips and remove the cover;
- Undo the two screws indicated on both sides of
the vehicle;
- Lift the rear of the cover to access the clamp fas-
tening the bellow to the fuel tank, and detach the
clamp with a screwdriver;
- Remove the chassis central cover.
Legshield
To remove the front shield, proceed as follows:
- Remove the frame central cover;
- Undo the indicated screw on both sides of the
vehicle;
Chassis Beverly 300 i.e.
CHAS - 256
