Refitting the hub bearings
- Install the three shafts in the engine crankcase
as shown in the figure.
Refitting the ub cover
- Fit a new gasket together with the alignment
dowels.
- Seal the gasket of the breather pipe using black
silicone sealant.
- Fit the gearbox cover, making sure the breather
pipe is in the correct position.
- Position the shorter screw that can also be rec-
ognised from the different colour as shown in the
figure.
- Fix the breather tube support by means of the
lower screw.
- Fit the remaining screws and tighten the seven
screws to the prescribed torque.
Locking torques (N*m)
Hub cover fixing screws 24 to 27 Hub oil drain
screws 15 to 17
Flywheel cover
Engine Beverly 300 i.e.
ENG - 130
